Dimensions
250 mm x 145 mm x 15 mm (9.8” x 5.7” x 0.6”)
Weight
635 g (22.4 oz)
Processor
Qualcomm® Snapdragon 625 MSM8953, 8 cores 2.0 GHz
Graphics
Adreno 506
RAM and Storage
4 GB / 64 GB
Operating System
Android 11 GMS
Android Enterprise Recommended
Display
8” capacitive multi-touch (10 points)
1920×1200 pixels
Sunlight readable
Glove/rain mode
Corning® Gorilla® Glass
Buttons
Front
Power, F1, F2, F3, Volume up/down
Battery
3.8V 8200 mAh (31.16 Wh), field replaceable
Ports
Type-C, OTG
GNSS antenna connector
Docking connector supporting HDMI, Ethernet, USB
Back connector for expandability
3.5mm headphone jack
1x micro SDXC (128 GB)
1x Nano-SIM
Communication
Cellular (WWAN)
2G (850,900,1800,1900)
3G (1,2,5,8)
4G/LTE (1,2,3,4,5,7,8,12,13,17,20,25,28,38,39,40,41)
*Data only
Wireless LAN
2.4GHz/5GHz
802.11a/b/g/n/ac
PAN
BT V4.1
Up to 150m
NFC
13.56 MHz
ISO 14443A/B, ISO 15693
Audio
Rear-facing speaker
Microphone
Positioning
Dedicated u-blox GNSS receiver
GPS/GLONASS/Galileo/BeiDou/SBAS
Cameras
Rear: 13 megapixel with autofocus and flash
Front: 5 megapixel
Sensors
Gyroscope
Compass
Accelerometer
Pressure
Proximity
Ambient light
Environment
Operating
-20°C to 60°C (-4°F to 140°F)
MIL-STD-810G, Method 501.5/502.5 Procedure II
Storage
-40°C to 70°C (-40°F to 158°F)
MIL-STD-810G, Method 501.5/502.5 Procedure I
Drop / Shock
26 drops from 1.2 m (4 ft)
MIL-STD-810G, Method 516.6 Procedures IV
Vibration
MIL-STD-810G, Method 514.6 Procedure I
Sand / Dust
IP67, IEC 60529
Water
IP67, IEC 60529
Humidity
0% ～ 95% (non-condensing)
MIL-STD-810G, Method 507.5 Procedure II
Altitude
4572 m (15 000 ft.)
MIL-STD-810G, Method 500.5 Procedures I & II
EMC/EMI
MIL-STD-461F: CE101, CE102, CS101, CS114, CS115, CS116, RE101, RE102, RS101, RS103
